Description

By using this AD8436BRQZ RMS to DC converter by Analog Devices you can switch your circuit"s RMS voltage to a DC one. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This RMS to DC converter has an operating temperature range of -40 °C to 125 °C.

Show

AD8436BRQZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	QSOP-20
Output Current	365 μA
Supply Current	325 µA
Number of Positions	20 Position
Input Current	300 µA
Power Dissipation	1.1 W
Bandwidth	1 MHz
Output Current (Max)	365 µA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	1000 kHz
Power Dissipation (Max)	2100 mW
Accuracy	0.5 %
Supply Voltage	2.4V ~ 18V
Input Voltage	2.4V ~ 18V
	Show
Size-Length	8.76 mm
Size-Width	4.01 mm
Size-Height	1.65 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance Edition	2014/06/16
ECCN Code	EAR99
