Image is for your reference only,please check specifications for details
- AD8508ARUZ - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC1052644
-
Category:Operational Amplifier, OP Amp IC
-
Package:TSSOP-14
-
Datasheet:Datasheet 3D Model
-
Description:ANALOG DEVICES AD8508ARUZ Operational Amplifier, Quad, 4 Amplifier, 95kHz, 0.013V/µs, 1.8V to 5V, ± 900mV to ± 2.5V, TSSOP
-
Stock Locations:
-
Availability:228 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 1.96
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Product Details
- The AD8505/AD8506/AD8508 are single, dual, and quad micro-power amplifiers featuring rail-to-rail input/output swings while operating from a single 1.8 V to 5 V power supply or from dual ±0.9 V to ±2.5 V power supplies. Using a new circuit technology, these amplifiers offer zero input crossover distortion (excellent PSRR and CMRR performance) and low bias current while operating with a supply current of less than 20 μA per amplifier. This amplifier family offers the lowest noise in its power class.
- This combination of features makes the AD8505/AD8506/AD8508 amplifiers ideal choices for battery-powered applications because they minimize errors due to power supply voltage variations over the lifetime of the battery and maintain high CMRR even for a rail-to-rail input op amp. Remote battery-powered sensors, handheld instrumentation, consumer equipment, hazard detection (for example, smoke, fire, and gas), and patient monitors can benefit from the features of the AD8505/AD8506/AD8508 amplifiers.
- The AD8505/AD8506/AD8508 are specified for both the industrial temperature range of −40°C to +85°C and the extended industrial temperature range of −40°C to +125°C. The AD8505 single ampli-fier is available in a tiny 5-lead SOT-23 package. The AD8506 dual amplifier is available in 8-lead MSOP and 8-ball WLCSP packages. The AD8508 quad amplifier is available in 14-lead TSSOP and 14-ball WLCSP packages. The AD8505/AD8506/AD8508 are members of a growing series of zero crossover distortion op amps offered by Analog Devices, Inc., including the ADA4505-1/ ADA4505-2/ADA4505-4, that operate from a single 1.8 V to 5 V supply or from dual ±0.9 V to ±2.5 V power supplies.
- **Applications**
- * Pressure and position sensors
- * Remote security
- * Bio sensors
- * IR thermometers
- * Battery-powered consumer equipment
- * Hazard detectors
- ### Features and Benefits
- PSRR: 100 dB minimum
- CMRR: 105 dB typical
- Very low supply current: 20 μA per amplifier maximum
- 1.8 V to 5 V single supply or ±0.9 V to ±2.5 V dual supply
- Rail-to-rail input/output
- Low noise: 45 nV/√Hz at 1 kHz
- 2.5 mV offset voltage maximum
- Very low input bias current: 1 pA typical
AD8508ARUZ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 14 Pin |
| Case/Package | TSSOP-14 |
| Supply Current | 15 µA |
| Number of Circuits | 4 Circuit |
| Number of Channels | 4 Channel |
| Number of Positions | 14 Position |
| Common Mode Rejection Ratio | 105 dB |
| Input Capacitance | 4.20 pF |
| Bandwidth | 95 kHz |
| Slew Rate | 13.0 mV/μs |
| Gain Bandwidth Product | 0.095 MHz |
| Input Offset Voltage | 500 µV |
| Input Bias Current | 1 pA |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Gain Bandwidth | 95 kHz |
| Minimum CMRR Range | 90 dB |
| Supply Voltage (Max) | 5 V |
| Supply Voltage (Min) | 1.8 V |
| Show | |
| Size-Length | 5.1 mm |
| Size-Width | 4.5 mm |
| Size-Height | 1 mm |
| Operating Temperature | -40℃ ~ 125℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Contains Lead |
| REACH SVHC Compliance | No SVHC |
| Mil-Spec | No |
| REACH SVHC Compliance Edition | 2015/12/17 |
