AD8556ARZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC212613
Category:
Amplifier, Buffer IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD8556ARZ Programmable/Variable Amplifier, 1Channels, 1 Amplifier, 700kHz, -40℃, 140℃, 2.7V to 5.5V
Stock Locations:
Availability:
605 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 4.59

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8556ARZ is a zero-drift Sensor Signal Amplifier with digitally programmable gain, output offset and EMI filters. Designed to easily and accurately convert variable pressure sensor and strain bridge outputs to a well-defined output voltage range, the AD8556 accurately amplifies many other differential or single-ended sensor outputs. The AD8556 uses the Analog Devices, Inc. patented low noise, auto-zero and DigiTrim® technologies to create an incredibly accurate and flexible signal processing solution in a very compact footprint. Gain is digitally programmable in a wide range from 70 to 1280 through a serial data interface. Gain adjustment can be fully simulated in-circuit and then permanently programmed with reliable polyfuse technology. Output offset voltage is also digitally programmable and is ratiometric to the supply voltage. The AD8556 also features internal EMI filters on the VNEG, VPOS, FILT and VCLAMP pins.
EMI filters at input pins
Digitally programmable gain and output offset voltage
Programmable output clamp voltage
Open and short wire fault detection
Low-pass filtering
Single-wire serial interface
Stable with any capacitive load
10µV Maximum low offset voltage
65nV/°C Maximum low input offset voltage drift

Show

AD8556ARZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	5.50 V
Supply Current	2 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	80 dB
Bandwidth	700 kHz
Slew Rate	1.20 V/μs
Gain Bandwidth Product	8 MHz
Input Offset Voltage	2 µV
Input Bias Current	49 nA
Operating Temperature (Max)	140 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	80 dB
Minimum CMRR Range	80 dB
Supply Voltage	2.7V ~ 5.5V
Supply Voltage (Max)	5V ~ 7V
	Show
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 140℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
