ADG1209YRZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC235904
Category:
Analog Switch Ic, Analog Switch Multiplexer
Package:
SOIC-16
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADG1209YRZ 4:1 Analog Multiplexer IC, Dual, 120Ω, 10.8V to 13.2V, SOIC-16
Stock Locations:
Availability:
256 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 2.57

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADG1209 series Analog Multiplexer comprising four differential channels. The IC switches one of four differential inputs to a common differential output as determined by the 2-bit binary address lines A0 and A1. The industrial CMOS (iCMOS) modular manufacturing process combines high voltage complementary metal-oxide semiconductor (CMOS) and bipolar technologies. It enables the development of a wide range of high performance analog ICs capable of 33V operation in a footprint that no other generation of high voltage devices has been able to achieve. The ultralow capacitance and exceptionally low charge injection of these multiplexers make them ideal solutions for data acquisition and sample-and-hold applications, where low glitch and fast settling are required.
<1pC Charge injection over full signal range
1pF Off capacitance
120R ON resistance
Fully specified at ±15V, +12V
3V Logic-compatible inputs
Rail-to-rail operation
Break-before-make switching action

Show

ADG1209YRZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	12.0V (min)
Number of Outputs	2 Output
Supply Current	220 µA
Number of Circuits	2 Circuit
Number of Channels	4 Channel
Number of Positions	16 Position
Power Dissipation	4.8 mW
Bandwidth	550 MHz
Number of Inputs	8 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	550 MHz
Supply Voltage (Max)	15 V
Supply Voltage (Min)	12 V
	Show
Size-Length	10 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
