ADG1401BRMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC2635200
Category:
Analog Switch Ic, Analog Switch Multiplexer
Package:
MSOP-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADG1401BRMZ Analogue Switch, Single Channel, SPST, 1Channels, 1.3Ω, ± 5V, 12V, ± 15V, MSOP, 8Pins
Stock Locations:
Availability:
3,950 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 6.56

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADG1401BRMZ is a single-pole single-throw (SPST) iCMOS Analog Switch for sample-and-hold systems. The switch with a logic 1 input, the switch is closed. It conducts equally well in both directions when on and has an input signal range that extends to the supplies. In the off condition, signal levels up to the supplies are blocked. The iCMOS® (industrial CMOS) modular manufacturing process combines high voltage, complementary metal-oxide semiconductor (CMOS) and bipolar technologies. It enables the development of a wide range of high performance analog ICs capable of 33V operation in a footprint that no other generation of high voltage parts has achieved. Unlike analog ICs using conventional CMOS processes, iCMOS components can tolerate high supply voltages while providing increased performance, dramatically lower power consumption and a reduced package size.
No VL supply required
3V Logic-compatible inputs
Rail-to-rail operation
Minimum distortion
Up to 430mA continuous current

Show

ADG1401BRMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Number of Outputs	1 Output
Supply Current	60 µA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Power Dissipation	1.44 mW
Bandwidth	120 MHz
Number of Inputs	1 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	120 MHz
	Show
Size-Length	3.2 mm
Size-Width	3.2 mm
Size-Height	0.95 mm
Operating Temperature	-40℃ ~ 125℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
