ADM3054 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC79559463
Category:
CAN IC, Controller Area Network
Package:
SOIC
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADM3054 CAN Bus, Transceiver, CAN, 1, 1, 3V, 5.5V, SOIC
Stock Locations:
Availability:
90 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 4.25

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADM3054 is a 5kVrms Signal Isolated Controller Area Network (CAN) Transceiver with bus protection. The transceiver employs the iCoupler® technology to combine a 3-channel isolator and a CAN transceiver. The logic side of the device is powered with a single 3.3 or 5V supply on VDD1 and the bus side uses a single 5V supply on VDD2 only. Loss of power on the bus side (VDD2) can be detected by an integrated VDD2SENSE signal. The ADM3054 creates an isolated interface between the CAN protocol controller and the physical layer bus. It is capable of running at data rates of up to 1Mbps. The device has integrated protection on the bus pins, CANH and CANL against shorts to power/ground in 24V systems. The device has current-limiting and thermal shutdown features to protect against output short circuits and situations where the bus might be shorted to ground or power terminals.
5kV rms Signal isolated CAN transceiver
VDD2SENSE to detect loss of power on VDD2
High speed data rates of up to 1Mbps
Short-circuit protection on CANH and CANL against shorts to power/ground in 24V systems
Unpowered nodes do not disturb the bus
Connect 110 or more nodes on the bus
Thermal shutdown protection
High common-mode transient immunity (>25kV/µs)
ESD sensitive device, take proper precaution while handling the device.

Show

ADM3054 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC
Supply Voltage (DC)	3.00V (min)
Number of Positions	16 Position
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	Show
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
