Description

The AD8495ARMZ is a precision thermocouple amplifier with cold junction compensation in 8 pin MSOP package. It produces high level (5mV/°C) output directly from thermocouple signal by combining an ice point reference with pre-calibrated amplifier. This device can be used as standalone thermometer or as switched output setpoint controller using either fixed or remote setpoint control. The AD8495A can be powered from single ended supply (less than 3V) and can measure temperatures below 0°C by offsetting the reference input. To minimize self heating, an unloaded AD8495A typically operates with total supply current of 180µA and it is also capable of delivering in excess of ±5mA to a load. The AD8495A is laser trimmed to match the characteristics of K type (chromel alumel) thermocouples.
Low cost and easy to use
Pretrimmed for K type thermocouple
Optimized ambient temperature (reference junction) from 0°C to 50°C
High impedance differential input
Reference pin allows offset adjustment
Thermocouple break detection
Temperature accuracy of 3°C
Low power of less than 1mW at VS = 5V
Single supply voltage from 2.7V to 36V and dual supply range from ±2.7V to ±18V
Operating temperature range from -40°C to 125°C
ESD (electrostatic discharge) sensitive device. Proper ESD precautions are recommended to avoid performance degradation or loss of functionality.

Show

AD8495ARMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Supply Voltage (DC)	2.70V (min)
Supply Current	250 µA
Number of Positions	8 Position
Gain Bandwidth Product	25 kHz
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	36 V
Supply Voltage (Min)	2.7 V
	Show
Size-Length	3.2 mm
Size-Width	3.2 mm
Size-Height	0.95 mm
Operating Temperature	0℃ ~ 50℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2013/06/20
ECCN Code	EAR99
