Image is for your reference only,please check specifications for details

AMC1210IRHAT - TI
Manufacturer:
TI
ManyChip's Part#:
MC7879030
Category:
Active Filter
Package:
QFN-40
Datasheet:
Datasheet 3D Model
Description:
Analog to Digital Converter 4Channel Digital Filter for ADS120X family of modulators Digital Filter 40Pin VQFN EP T/R
Stock Locations:
Availability:
291 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 2.25

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AMC1210IRHAT is a four-channel Digital Filter designed specifically for current measurement and resolver position decoding in motor control applications. Each input can receive an independent delta-sigma () modulator bit stream. The bit streams are processed by four individually-programmable digital decimation filters. The AMC1210 also offers a flexible interface and a comprehensive interrupt unit, allowing customized digital functionality and immediate digital threshold comparisons for over-current monitoring.
Four window comparators
Three parallel and one serial interface
Comprehensive interrupt system
Programmable input configuration
Carrier frequency generator for resolver applications

Show

AMC1210IRHAT Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	40 Pin
Case/Package	QFN-40
Supply Voltage (DC)	4.50V (min)
Number of Channels	4 Channel
Number of Positions	40 Position
Number of Bits	8 Bit
Power Consumption	24.5 mW
Number of Inputs	4 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Number of Input Channels	4 Channel
Supply Voltage	2.4V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	Show
Size-Length	6 mm
Size-Width	6 mm
Size-Height	0.9 mm
Weight	0.0016637769232 kg
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
