Description

The SN74154N is a 4 to 16-line Decoder or Demultiplexer utilizes TTL circuitry to decode four binary-coded inputs into one of sixteen mutually exclusive outputs when both the strobe inputs, The demultiplexing function is performed by using the 4 input lines to address the output line, passing data from one of the strobe inputs with the other strobe input low. When either strobe input is high, all outputs are high. The demultiplexes are ideally suited for implementing high performance memory decoders.
Performs demultiplexing function by distributing data from one input line to any one of 16 outputs
Input clamping diodes simplify system design
High fan-out, low-impedance, totem pole outputs
Fully compatible with most TTL and MSI circuits

Show

SN74154N Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	24 Pin
Case/Package	DIP-24
Supply Voltage (DC)	4.75V ~ 5.25V
Number of Outputs	16 Output
Output Voltage	2.4V ~ 0.4V
Output Current	56 mA
Number of Circuits	1 Circuit
Number of Channels	4 Channel
Number of Positions	24 Position
Number of Bits	16 Bit
Voltage Nodes	5.00 V
Output Current Drive	-50.0 µA
Output Current (Max)	16 mA
Number of Inputs	4 Input
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Supply Voltage	4.75V ~ 5.25V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	4.75 V
Input Voltage	2.0V ~ 0.8V
	Show
Size-Length	31.75 mm
Size-Width	13.71 mm
Size-Height	4.57 mm
Weight	0.0597648810316 kg
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/12/17
