Description

General Description
The AO4806 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. They offer operation over a wide gate drive range from 1.8V to 12V. It is ESD protected. This device is suitable for use as a uni-directional or bi-directional load switch, facilitated by its common-drain configuration.
Standard Product AO4806 is Pb-free (meets ROHS & Sony 259 specifications). AO4806L is a Green Product ordering option. AO4806 and AO4806L are electrically identical.
Features
• VDS (V) = 20V
• ID = 9.4A (VGS = 10V)
• RDS(ON) < 14mΩ (VGS = 10V)
• RDS(ON) < 15mΩ (VGS = 4.5V)
• RDS(ON) < 21mΩ (VGS = 2.5V)
• RDS(ON) < 30mΩ (VGS = 1.8V)
• ESD Rating: 2000V HBM

Show

AO4806 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Case/Package	SOIC-8
Power Rating	1.28 W
Polarity	N-CH
Drain to Source Voltage (Vds)	20 V
Continuous Drain Current (Ids)	9.4A
Input Capacitance (Ciss)	1810pF @10V(Vds)
Input Power (Max)	2 W
Power Dissipation (Max)	2 W
	Show
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
