Description
- Chopper Regulator, DC−DC Converter and Motor Drive Applications
- • 4-V gate drive
- • Low drain−source ON resistance : RDS (ON) = 8 mΩ (typ.)
- • High forward transfer admittance : |Yfs| = 60 S (typ.)
- • Low leakage current : IDSS = 100 μA (max) (VDS = 60 V)
- • Enhancement mode : Vth = 0.8 to 2.0 V (VDS = 10 V, ID = 1 mA)
2SK2313 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Case/Package | SC-65 |
| Voltage Rating (DC) | 60.0 V |
| Current Rating | 60.0 A |
| Polarity | N-CH |
| Drain to Source Voltage (Vds) | 60.0 V |
| Continuous Drain Current (Ids) | 60.0 A |
| Rise Time | 30.0 ns |
| Show | |
| Product Lifecycle Status | Active |
| Packaging | Bulk |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
