Description

The BTS5210G is a high-side Power Switch with integrated vertical power FET and providing embedded protection and diagnostic functions. The design is based on monolithically integrated in smart SIPMOS® chip on chip technology.
Very low standby current
CMOS compatible input
Improved electromagnetic compatibility
Fast demagnetization of inductive loads
Stable behaviour at under-voltage
Wide operating voltage range
Logic ground independent from load ground
High voltage capability
Benchmark energy robustness
ESD sensitive device, take proper precaution while handling the device.

Show

BTS5210G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	PG-DSO-14
Supply Voltage (DC)	5.00V (min)
Number of Outputs	2 Output
Output Current	1.8 A
Number of Channels	2 Channel
Number of Positions	14 Position
Power Dissipation	3.05 W
Output Current (Max)	1.8 A
Output Current (Min)	1.8 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	3050 mW
Supply Voltage	5.5V ~ 40V
	Show
Size-Length	8.75 mm
Size-Width	4 mm
Size-Height	1.47 mm
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
