Description
- The BTS4141N is a N-channel high-side vertical power FET Switch with charge pump and monolithically integrated in smart SIPMOS® technology. It provides embedded protective functions and thermal shutdown with restart.
- Overload protection
- Overvoltage protection
- Under-voltage shutdown with auto restart and hysteresis
- Switching inductive load
- Clamp of negative output voltage with inductive loads
- CMOS compatible input
- ESD protection
- Loss GND and loss VBB protection
- Very low stand by current
- Reverse battery protection with external resistor
- Improved electromagnetic compatibility(EMC)
- ESD sensitive device, take proper precaution while handling the device.
BTS4141N Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 4 Pin |
| Case/Package | SOT-223-4 |
| Number of Outputs | 1 Output |
| Output Voltage | 12.45 V |
| Output Current | 0.7 A |
| Number of Channels | 1 Channel |
| Number of Positions | 4 Position |
| Power Dissipation | 1.4 W |
| Output Current (Min) | 0.7 A |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 1400 mW |
| Supply Voltage | 12V ~ 45V |
| Show | |
| Size-Length | 6.5 mm |
| Size-Width | 3.5 mm |
| Size-Height | 1.6 mm |
| Operating Temperature | -40℃ ~ 125℃ |
| Product Lifecycle Status | Not Recommended for New Design |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/12/17 |
| ECCN Code | EAR99 |
