Image is for your reference only,please check specifications for details
- APT1222 - Panasonic
-
Manufacturer:Panasonic
-
ManyChip's Part#:MC19659277
-
Category:Optocoupler, Optoisolator
-
Package:DIP-6
-
Datasheet:Datasheet 3D Model
-
Description:PANASONIC ELECTRIC WORKS APT1222 Optocoupler, Triac Output, DIP, 6Pins, 5kV, Non Zero Crossing, 600V
-
Stock Locations:
-
Availability:234 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.74
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Optoisolator Triac Output 5000Vrms 1 Channel 6-DIP
APT1222 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 6 Pin |
| Case/Package | DIP-6 |
| Supply Voltage (DC) | 600 V |
| Output Voltage | 600 V |
| Output Current | 0.1 A |
| Contacts Type | SPST-NO |
| Number of Channels | 1 Channel |
| Load Current | 100 mA |
| Forward Voltage | 1.21 V |
| Input Current | 20.0 mA |
| Power Dissipation | 0.5 W |
| Isolation Voltage | 5000 Vrms |
| Holding Current | 3.5 mA |
| Forward Current | 50 mA |
| Input Voltage (Max) | 1.3 V |
| Output Voltage (Max) | 420 VAC |
| Reverse Breakdown Voltage | 6 V |
| Maximum Forward Voltage (Max) | 1.3 V |
| Load Current (Max) | 3.5 mA |
| Load Current (Min) | 0.3 mA |
| Forward Current (Max) | 50 mA |
| Operating Temperature (Max) | 100 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 500 mW |
| Show | |
| Size-Length | 8.8 mm |
| Size-Width | 6.40 mm |
| Size-Height | 3.9 mm |
| Operating Temperature | -40℃ ~ 100℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| HTS Code | 8541408000 |
| ECCN Code | EAR99 |
