Image is for your reference only,please check specifications for details
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- **Epcos B82144A LBC Series Axial Inductors**
- Epcos B82144A LBC series RF chokes are suitable for use in telecommunications (12- or16-kHZ blocking filter), automotive electronics, energy saving lamps and entertainment electronics. They can also be used for RF blocking and filtering and decoupling and interference suppression. These inductors consist of a large ferrite drum core with enamel copper wire winding and a flame retardant lacquer coating.
B82144A2105J000 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Axial |
| Number of Pins | 2 Pin |
| Current Rating | 200 mA |
| Capacitance Tolerance | ±5 % |
| Inductance | 1 mH |
| Self Resonant Frequency | 1.2 MHz |
| Q-Factor | 60.0 |
| Inductance Tolerance | ±5 % |
| Test Frequency | 0.1 MHz |
| DC Resistance (DCR) | 3.8 Ω |
| Current Rating (DC) | 200 mA |
| Resistance (DC Max) | 3.8 Ω |
| Show | |
| Size-Length | 14.8 mm |
| Size-Diameter | 5.20 mm |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
