- BAV170 - NXP
-
Manufacturer:NXP
-
ManyChip's Part#:MC116254387
-
Category:Small Signal Diode
-
Package:SOT-23
-
Datasheet:Datasheet 3D Model
-
Description:DIODE 0.215A, 85V, 2Element, SILICON, SIGNAL DIODE, TO-236AB, PLASTIC PACKAGE-3, Signal Diode
-
Stock Locations:
-
Availability:1,871 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.05
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The BAV170 is an epitaxial medium-speed switching double Diode in a small SOT23 surface-mounted device SMD plastic package. The diodes are in common cathode configuration. It is used for low leakage current applications in surface mounted circuits.
- 75V Continuous reverse voltage (maximum)
- 500mA Repetitive peak forward current
- 3pA Low reverse current (typ.)
- AEC-Q101 qualified
BAV170 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 3 Pin |
| Case/Package | SOT-23 |
| Number of Positions | 3 Position |
| Reverse recovery time | 3 µs |
| Forward Current | 215 mA |
| Max Forward Surge Current (Ifsm) | 4 A |
| Maximum Forward Voltage (Max) | 1.25 V |
| Forward Current (Max) | 215 mA |
| Operating Temperature (Max) | 150 ℃ |
| Show | |
| Size-Length | 3 mm |
| Size-Width | 1.4 mm |
| Size-Height | 1 mm |
| Product Lifecycle Status | Unknown |
| Packaging | Cut Tape (CT) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/12/17 |
