Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 2 Pin |
Case/Package | Radial, Box |
Pin Pitch | 5.08 mm |
Voltage Rating (DC) | 63 V |
Voltage Rating (AC) | 40 V |
Insulation Resistance | 500 MΩ |
Capacitance | 0.1 µF |
Capacitance Tolerance | ±10 % |
Part Family | MKT370 |
Operating Temperature (Max) | 100 ℃ |
Operating Temperature (Min) | -55 ℃ |
Voltage Rating | 63 V |
Show | |
Size-Length | 7.2 mm |
Size-Width | 2.5 mm |
Size-Height | 6.5 mm |
Lead Length | 4 mm |
Material | PET |
Dielectric Material | Polyester |
Operating Temperature | -55℃ ~ 100℃ |
Product Lifecycle Status | Active |
Packaging | Bulk |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
