MAX901 - Maxim Integrated
Manufacturer:
Maxim Integrated
ManyChip's Part#:
MC1208219357
Category:
Comparator, Analog Comparator IC
Package:
PDIP
Datasheet:
Datasheet 3D Model
Description:
The MAX900–MAX903 high-speed, low-power, single/dual/quad voltage comparators feature differential analog inputs and TTL-logic outputs with active internal pullups
Stock Locations:
Availability:
303 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

General Description
The MAX900–MAX903 high-speed, low-power, single/dual/quad voltage comparators feature differential analog inputs and TTL-logic outputs with active internal pullups. Fast propagation delay (8ns typ at 5mV overdrive) makes the MAX900–MAX903 ideal for fast A/D convert ers and sampling circuits, line receivers, V/F converters, and many other data-discrimination applications.
Features
8ns (typ) Propagation Delay
18mW/Comparator Power Consumption (+5V, typ)
Separate Analog and Digital Supplies
Flexible Analog Supply: +5V to +10V or ±5V
Input Range Includes Negative Supply Rail
TTL-Compatible Outputs
TTL-Compatible Latch Inputs (Except MAX901)
Applications
High-Speed A/D
Converters
High-Speed V/F
Converters
Line Receivers
Threshold Detectors
Input Trigger Circuitry
High-Speed Data
Sampling
PWM Circuits
