Description

The BFR 360F H6327 is a NPN Silicon RF Transistor for low-noise amplifier for low current applications. The device is suitable for amplifier and oscillator applications in RF front-end. The collector design of the device supports 5V supply voltage.
Low noise figure

Show

BFR360FH6327XTSA1 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	PG-TSFP-3
Frequency	14000 MHz
Number of Positions	3 Position
Polarity	NPN
Power Dissipation	210 mW
Input Capacitance	0.4 pF
Breakdown Voltage (Collector to Emitter)	9 V
Gain	15.5 dB
hFE Min	90 @15mA, 3V
Input Power (Max)	210 mW
DC Current Gain (hFE)	90
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	210 mW
	Show
Size-Length	1.2 mm
Size-Width	0.8 mm
Size-Height	0.55 mm
Material	Silicon
Operating Temperature	150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
