Description

The BTS723GW is a 2-channel high-side Power Switch providing embedded protection functions. The device is monolithically integrated in smart SIPMOS® technology. The power transistor is built by N-channel-planar power MOSFET with a charge pump which boosts the battery voltage. The inputs are ground referenced CMOS compatible.
Improved electromagnetic compatibility
Fast demagnetization of inductive loads
Stable behaviour at under-voltage
Logic ground independent from load ground
Wide operating voltage range
Optimized inverse current capability
Short-circuit protection
Overload protection
Current limitation
Thermal shutdown
Overvoltage protection
Loss of ground and loss of VBB protection
Reverse battery protection with external resistor
ESD sensitive device, take proper precaution while handling the device.

Show

BTS723GWXUMA1 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	DSO-14-37
Number of Outputs	2 Output
Input Voltage (DC)	42.0 V
Output Current	2.5 A
Supply Current	2 mA
Number of Positions	14 Position
Power Dissipation	3 W
Output Current (Min)	2.5 A
Number of Inputs	2 Input
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	3000 mW
Input Voltage	42 V
	Show
Size-Length	8.75 mm
Size-Width	4 mm
Size-Height	1.47 mm
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
