Description

The C44A series from Kemet are aluminium case general purpose chassis mount metalized polypropylene film capacitors. These capacitors are approved by VDE 0560, IEC 071 and EN 61071 standards. They also have IEC climatic category (40/85/21) and IP00 degree of protection.
Capacitance value ranges from 1µF to 330µF
Available in 400VDC, 600VDC, 700VDC, 850VDC, 1200VDC and 1500VDC rated voltages
±5% and ±10% tolerance values
Life expectancy of >= 30000hours at URMS and >= 100.000 hours at Un
Tinned brass fastons or screws
Rated insulation voltage (Ui) of 700V at 50Hz (insulation group B ( VDE 0110 part 1))
Maximum permissible ambient temperature of 70°C

Show

C44AFFP5500ZE0J Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Screw
Pin Pitch	22.3 mm
Voltage Rating (DC)	400 V
Voltage Rating (AC)	250 V
Capacitance	50 µF
Equivalent Series Resistance (ESR)	6 mΩ
Capacitance Tolerance	±5 %
Part Family	C44A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Voltage Rating	250 VAC
	Show
Size-Length	101 mm
Size-Height	101 mm
Lead Length	1.3 mm
Dielectric Material	Polypropylene
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
