Description

This 16.2-mΩ, –8-V, P-Channel device is designed to deliver the lowest on-resistance and gate charge in a small 1 × 1.5 mm outline with excellent thermal characteristics in an ultra-low profile.

Show

CSD23203W Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	DSBGA-6
Polarity	P-CH
Power Dissipation	0.75 W
Drain to Source Voltage (Vds)	8 V
Continuous Drain Current (Ids)	3A
Rise Time	12 ns
Input Capacitance (Ciss)	914pF @4V(Vds)
Input Power (Max)	750 mW
Fall Time	27 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	750mW (Ta)
	Show
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
