Image is for your reference only,please check specifications for details
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The DG413DY is a single-pole single-throw precision monolithic quad Analogue Switch designed to provide high speed, low error switching of precision analogue signals. To achieve high-voltage ratings and superior switching performance, this is built on high voltage silicon gate process. Each switch conducts equally well in both directions when ON and blocks input voltages up to the supply levels when OFF.
- An epitaxial layer prevents latch-up
- TTL/CMOS compatible
- Single supply capability
- Widest dynamic range
- Low signal errors and distortion
- Break-before-make switching action
- Simple interfacing
- -40 to 85°C Temperature range
DG413DY Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 16 Pin |
| Case/Package | SOIC-16 |
| Supply Voltage (DC) | 44.0 V |
| Number of Outputs | 4 Output |
| Supply Current | 1 µA |
| Number of Channels | 4 Channel |
| Number of Positions | 16 Position |
| Power Dissipation | 0.6 W |
| Number of Inputs | 4 Input |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 600 mW |
| Supply Voltage | 44V ~ 15V |
| Show | |
| Operating Temperature | -40℃ ~ 85℃ |
| Packaging | Tube |
| RoHS | Non-Compliant |
