DRV8704DCPR - TI
Manufacturer:
TI
ManyChip's Part#:
MC37247393
Category:
Motor Driver
Package:
HTSSOP-38
Datasheet:
Datasheet 3D Model
Description:
TEXAS INSTRUMENTS DRV8704DCPR Motor Driver/Controller, DC Brush, 8V to 52V supply, 400mA/2Outputs, HTSSOP-38 New
Stock Locations:
Availability:
242 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 20.16

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The DRV8704 is a dual-brushed motor controller for industrial equipment applications. The device controls external N-channel MOSFETs configured as two H-bridges.
Motor current can be accurately controlled using adaptive blanking time and various current decay modes, including an automatic mixed decay mode.
A simple PWM interface allows easy interfacing to controller circuits. A SPI serial interface is used to program the device operation. Output current (torque), gate drive settings, and decay mode are all programmable through a SPI serial interface.
Internal shutdown functions are provided for overcurrent protection, short-circuit protection, gate driver faults, undervoltage lockout (UVLO), and overtemperature. Fault conditions are indicated by a FAULTn pin, and each fault condition is reported by a dedicated bit through SPI.
The DRV8704 is packaged in a PowerPAD 38-pin HTSSOP package with thermal pad (Eco-friendly: RoHS & no Sb/Br).

Show

DRV8704DCPR Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	38 Pin
Case/Package	HTSSOP-38
Supply Voltage (DC)	8.00V (min)
Number of Outputs	2 Output
Output Voltage	4.8V ~ 5.2V
Output Current	400 mA
Number of Positions	38 Position
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	0V ~ 5.3V
Supply Voltage (Max)	52 V
Supply Voltage (Min)	8 V
	Show
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
