Image is for your reference only,please check specifications for details

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The DRV8824EVM is a DRV8824 stepper motor controller evaluation module, which provides an integrated motor driver solution. The DRV8824 device has two H-bridge drivers and a microstepping indexer, and is intended to drive a bipolar stepper motor. The output driver block for each consists of N-channel power MOSFET"s configured as full H-bridges to drive the motor windings. The DRV8824 is capable of driving up to 1.6A of output current (with proper heatsinking, at 24V and 25°C). A simple step/direction interface allows easy interfacing to controller circuits. Pins allow configuration of the motor in full step up to 1/32 step modes. Decay mode is programmable. Internal shutdown functions are provided for overcurrent protection, short circuit protection, undervoltage lockout and over temperature. The DRV8824 is available in a 28 pin HTSSOP package with PowerPAD(Eco friendly RoHS & no Sb/Br).
DRV8824 stepper motor controller
Easy to use GUI to allow for easy setup
Includes all necessary cabling and software to control DRV8824
PWM microstepping motor driver
Built In 3.3V reference output
8V to 45V operating supply voltage range
Thermally enhanced surface mount package

Show

DRV8824EVM Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
	Show
Product Lifecycle Status	Unknown
Packaging	Bulk
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
