Image is for your reference only,please check specifications for details

EL2125CSZ - Intersil
Manufacturer:
Intersil
ManyChip's Part#:
MC75731586
Category:
Operational Amplifier, OP Amp IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
INTERSIL EL2125CSZ Operational Amplifier, Single, 1 Amplifier, 180MHz, 190V/µs, ± 2.5V to ± 15V, SOIC, 8Pins
Stock Locations:
Availability:
184 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.54

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Show

EL2125CSZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	33.0 V
Output Current	≤40 mA
Supply Current	10.8 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Common Mode Rejection Ratio	80 dB
Bandwidth	180 MHz
Slew Rate	190 V/μs
Thermal Shutdown	No
Input Offset Voltage	2 mV
Input Bias Current	22000 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-45 ℃
3dB Bandwidth	220 MHz
Gain Bandwidth	175 MHz
Minimum CMRR Range	80 dB
Supply Voltage (Max)	33 V
Supply Voltage (Min)	5 V
	Show
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-45℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
