Description

The EPC2LC20N is a Configuration Device for SRAM-based LUT devices. With SRAM-based devices, configuration data must be reloaded each time the device powers up, the system initializes or when new configuration data is needed. Programming support with the Altera Programming Unit (APU) and programming hardware from Data I/O, BP Microsystems and other third-party programmers.
Easy-to-use 4-pin interface
Low current during configuration and near-zero standby mode current
EPC2 device has reprogrammable flash configuration memory

Show

EPC2LC20N Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	PLCC-20
Frequency	16.7 MHz
Supply Voltage (DC)	5.00 V, 5.25 V (max)
Supply Current	50 mA
Number of Positions	20 Position
Clock Speed	8 MHz
Memory Size	250000 B
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Supply Voltage	3V ~ 5V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	3 V
	Show
Size-Length	8.97 mm
Size-Width	8.97 mm
Size-Height	3.81 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
ECCN Code	EAR99
