Description

The ESD7104 transient voltage suppressor is designed to protect high speed data lines from ESD. Ultra-low capacitance and low ESD clamping voltage make this device an ideal solution for protecting voltage sensitive high speed data lines. The flow-through style package allows for easy PCB layout and matched trace lengths necessary to maintain consistent impedance between high speed differential lines such as USB 3.0 and HDMI.
Features
---
|
Low Capacitance (0.3 pF Typical, I/O to GND)
Protection for the Following IEC Standards: IEC 61000-4-2 (Level 4)
UL Flammability Rating of 94 V-0
This is a Pb-Free Device
Low ESD Clamping Voltage

Show

ESD7104MUTAG Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	UDFN-10
Operating Voltage	5 V
Capacitance	0.3 pF
Halogen Free Status	Halogen Free
Breakdown Voltage	5.5 V
Number of Circuits	4 Circuit
Number of Channels	4 Channel
Number of Positions	10 Position
Clamping Voltage	10 V
Test Current	1 mA
Min Breakdown Voltage	5.5 V
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
	Show
Size-Length	2.5 mm
Size-Width	1 mm
Size-Height	0.5 mm
Operating Temperature	-55℃ ~ 125℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
HK STC License	NLR
