Description

This FSCQ1265RTYDTU power switch by Fairchild Semiconductor will easily switch between two states. This charge controller has single output. This device has a maximum power dissipation of 50000 mW. It features 0.75 Ohm switch on resistance. This charge controller has an input voltage of -0.3 to 20 V. This device has a supply current of 6 mA and a minimum output current of 6.16 A. Its maximum power dissipation is 50000 mW. This product comes in rail packaging to keep individual parts separated and protected. This charge controller has an operating temperature range of -25 °C to 85 °C.

Show

FSCQ1265RTYDTU Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	5 Pin
Case/Package	TO-220-5
Frequency	20.0 kHz
Supply Voltage (DC)	20.0 V
Current Rating	7.00 A
Power Rating	170 W
Number of Outputs	1 Output
Input Voltage (DC)	20.0 V
Output Voltage	650 V, 650 V (max)
Output Current	6.16 A
Breakdown Voltage	650 V
Supply Current	6 mA
Power Dissipation	50 W
Quiescent Current	6.00 mA
Switching Frequency	20 kHz
Duty Cycle	95 %
Input Voltage (AC Max)	265 v
Input Voltage (AC Min)	85 v
Output Current (Min)	6.16 A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-25 ℃
Power Dissipation (Max)	50000 mW
Input Voltage	9V ~ 20V
	Show
Size-Length	10.16 mm
Size-Width	4.7 mm
Size-Height	15.87 mm
Operating Temperature	-25℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
HK STC License	NLR
