Description
- FSV12100V
- Features
- ---
- |
- Ultra-Low Forward Voltage Drop
- Low Thermal Resistance
- Very Low Profile: Typical Height of 1.1 mm
- Trench Schottky Technology
- RoHS Compliant
- Green Molding Compound as per IEC61249 Standard
- Lead Free in Compliance with EU RoHS 2011/65/EU Directive
- Qualified per AEC-Q101 Rev. C Standard
FSV12100V Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Number of Pins | 3 Pin |
| Case/Package | TO-277-3 |
| Number of Positions | 3 Position |
| Forward Voltage | 0.67 V |
| Reverse recovery time | 27.33 ns |
| Forward Current | 12000 mA |
| Max Forward Surge Current (Ifsm) | 220 A |
| Maximum Forward Voltage (Max) | 670 mV |
| Forward Current (Max) | 12000 mA |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Show | |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | Compliant with Exemption |
| Lead-Free Status | Lead Free |
