GBPC3510 - ON Semiconductor
Manufacturer:
ON Semiconductor
ManyChip's Part#:
MC4496589
Category:
Bridge Rectifier
Package:
Square-4
Datasheet:
Datasheet 3D Model
Description:
GBPC Series 1kV 1.1V 35A -55°/150℃ Stud Mount Bridge Rectifier - GBPC-1
Stock Locations:
Availability:
241 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 4.23

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The GBPC3510 is a 1-phase bridge Rectifier Diode with push-on terminals. Integrally molded heatsink provided very low thermal resistance for maximum heat dissipation.
Surge overload rating from 300 to 400A
Isolated voltage from case to lead over 2500V
UL certified
Silver terminal finish
1.5°C/W Junction to case thermal resistance
1.5°C/W Junction to case thermal resistance

Show

GBPC3510 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Number of Pins	4 Pin
Case/Package	Square-4
Number of Positions	4 Position
Forward Voltage	1.1 V
Power Dissipation	83300 mW
Thermal Resistance	1.5 ℃/W
Forward Current	35 A
Max Forward Surge Current (Ifsm)	400 A
Maximum Forward Voltage (Max)	1.1 V
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	83300 mW
	Show
Size-Length	29 mm
Size-Width	29 mm
Size-Height	11.23 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Bag
RoHS	Compliant with Exemption
Lead-Free Status
ECCN Code	EAR99
