Dual rectifiers suited for switch mode power supply and high frequency DC to DC converters.
Packaged in ISOTOP, this device is intended for use in low voltage, high frequency inverters, free wheeling operation, welding equipment and telecom power supplies.
Features
■ Combines highest recovery and reverse voltage performance
■ Ultra-fast, soft and noise-free recovery
■ Insulated package: ISOTOP
– insulated voltage: 2500 V rms
– capacitance: < 45 pF
■ Low inductance and low capacitance allow simplified layout

Show

STTH16003TV1 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	4 Pin
Case/Package	ISOTOP-4
Voltage Rating (DC)	300 V
Current Rating	180 A
Forward Voltage	1.2V @80A
Reverse recovery time	80 ns
Forward Current	160 A
Max Forward Surge Current (Ifsm)	800 A
Maximum Forward Voltage (Max)	1.2 V
Forward Current (Max)	160 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Junction Temperature	150℃ (Max)
	Show
Size-Length	38.2 mm
Size-Width	25.5 mm
Size-Height	9.1 mm
Operating Temperature	-55℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
