Image is for your reference only,please check specifications for details

GBU6J - Fairchild
Manufacturer:
Fairchild
ManyChip's Part#:
MC43665267
Category:
Bridge Rectifier
Package:
SIP-4
Datasheet:
Datasheet 3D Model
Description:
FAIRCHILD SEMICONDUCTOR GBU6J Bridge Rectifier Diode, Single, 600V, 6A, SIP, 1V, 4Pins
Stock Locations:
Availability:
1858 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.09

Updated at 17/07/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The GBU6J is a Bridge Rectifier with moulded plastic construction and glass-passivated junction. This bridge rectifier is general usage and suitable for many different applications.
420V Maximum RMS bridge input voltage
12W Power dissipation
UL Certified

Show

GBU6J Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	4 Pin
Case/Package	SIP-4
Voltage Rating (DC)	600 V
Current Rating	6.00 A
Capacitance	400 pF
Output Current	≤6.00 A
Number of Positions	4 Position
Forward Voltage	1V @6A
Power Dissipation	12 W
Forward Current	6 A
Max Forward Surge Current (Ifsm)	175 A
Maximum Forward Voltage (Max)	1 V
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
	Show
Size-Length	22.3 mm
Size-Width	3.56 mm
Size-Height	18.8 mm
Operating Temperature	-55℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	Non-Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
