HMC394LP4E - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC5821396
Category:
RF Module, IC, Accessory
Package:
QFN-24
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES HMC394LP4E Divide-By-N Counter, 2.2GHz, -999V to 5.5V, HQFN-24
Stock Locations:
Availability:
1,615 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 35.41

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The HMC394LP4E is a 5-bit low noise GaAs HBT Programmable Counter allows continuous division from N= 2 to 32 at input frequencies up to 2.2GHz. The output voltage swing is 800mV with a duty cycle inversely proportional to N. The low additive SSB phase noise of -153dBc/Hz at 100KHz offset makes this counter an excellent choice for low noise synthesizer applications.
Parallel 5-bit control

Show

HMC394LP4E Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	24 Pin
Case/Package	QFN-24
Frequency	0Hz ~ 2.2GHz
Supply Voltage (DC)	5.50V (max)
Supply Current	194 mA
Clock Speed	2.2 GHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-55 ℃
Supply Voltage (Max)	5.5 V
	Show
Size-Length	4.1 mm
Size-Width	4.1 mm
Size-Height	0.95 mm
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	3A001.a.11.b
