HMC516 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC2341375
Category:
Amplifier chip
Package:
Die
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES HMC516 RF Amplifier IC, 20.5dB Gain / 1.8dB Noise, 7GHz to 17GHz, 2.5V to 3.5V, Gel Pack
Stock Locations:
Availability:
284 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 72.86

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Product Details
The HMC516 chip is a high dynamic range GaAs PHEMT MMIC Low Noise Amplifier (LNA) which covers the 7 to 17 GHz frequency range. The HMC516 provides 20 dB of small signal gain, 1.8 dB of noise figure and has an output IP3 greater than +20 dBm. The chip can easily be integrated into hybrid or MCM assemblies due to its small size. All data is tested with the chip in a 50 Ohm test fixture connected via 0.075mm (3 mil) ribbon bonds of minimal length 0.31 mm (12 mil). Two 0.025 mm (1 mil) diameter bondwires may also be used to make the RFIN and RFOUT connections.
Applications
Point-to-Point Radios
Point-to-Multi-Point Radios & VSAT
Test Equipment and Sensors
Military & Space
### Features and Benefits
Noise Figure: 1.8 dB
Gain: 20 dB
OIP3: +20 dBm
Single Supply: 3V @ 65 mA
50 Ohm Matched Input/Output
Die Size: 2.52 x 1.32 x 0.1 mm

Show

HMC516 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Number of Pins	8 Pin
Case/Package	Die
Frequency	7GHz ~ 17GHz
Supply Voltage (DC)	2.50V (min)
Supply Current	65 mA
Number of Channels	1 Channel
Power Dissipation	1.25 W
Gain	20.5 dB
Test Frequency	7GHz ~ 17GHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	1250 mW
Supply Voltage	3 V
Supply Voltage (Max)	3.5 V
Supply Voltage (Min)	2.5 V
	Show
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
