HMC642ALC5 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC1448727
Category:
RF Module, IC, Accessory
Package:
SMD-32
Datasheet:
Datasheet 3D Model
Description:
Special Function IC, Phase Shifter, GaAs MMIC 6Bit Digital, 9GHz to 12.5GHz, 0 V to 5V, SMD-32
Stock Locations:
Availability:
242 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 384.82

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Product Details
The HMC642ALC5 is a 6-bit digital phase shifter which is rated from 9 to 12.5 GHz, providing 360 degrees of phase coverage, with a LSB of 5.625 degrees. The HMC642ALC5 features very low RMS phase error of 4.5 degrees and extremely low insertion loss variation of ±0.4 dB across all phase states. This high accuracy phase shifter is controlled with positive control logic of 0/+5V The HMC642ALC5 is housed in a compact 5x5 mm ceramic leadless SMT package and is internally matched to 50 Ohms with no external components.
**Applications**
EW Receivers
Weather and Military Radar
Satellite Communications
Beamforming Modules
Phase Cancellation
### Features and Benefits
Low RMS Phase Error: 4.5°
Low Insertion Loss: 7 dB
High Linearity: +35 dBm
Positive Control Logic
360° Coverage, LSB = 5.625°
32 Lead 5x5mm SMT Package: 25mm2

Show

HMC642ALC5 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	32 Pin
Case/Package	SMD-32
Frequency	9GHz ~ 12.5GHz
Supply Voltage (DC)	5.00V (max)
Number of Positions	32 Position
Number of Bits	6 Bit
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	5 V
	Show
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance Edition	2016/06/20
ECCN Code	EAR99
