IRAMX30TP60A - Infineon
Manufacturer:
Infineon
ManyChip's Part#:
MC44661159
Category:
Motor Driver
Package:
SIP-2
Datasheet:
Datasheet 3D Model
Description:
INFINEON IRAMX30TP60A Motor Driver, 3-Phase AC, 13.5V to 16.5V supply, 600V/30A/1 Output, SIP-23
Stock Locations:
Availability:
293 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 17.73

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Power Driver Module IGBT 3 Phase 600V 30A 23-PowerSIP Module, 19 Leads, Formed Leads

Show

IRAMX30TP60A Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	23 Pin
Case/Package	SIP-2
Supply Voltage (DC)	13.5V (min)
Number of Outputs	1 Output
Output Voltage	600 V
Output Current	30 A
Number of Positions	23 Position
Power Dissipation	41 W
Isolation Voltage	2000 Vrms
Switching Frequency	20.0 kHz
Operating Temperature (Max)	100 ℃
Operating Temperature (Min)	-20 ℃
Power Dissipation (Max)	41000 mW
Supply Voltage (Max)	16.5 V
Supply Voltage (Min)	13.5 V
	Show
Size-Length	62 mm
Size-Width	25.3 mm
Size-Height	5.5 mm
Operating Temperature	-20℃ ~ 100℃
Product Lifecycle Status	Obsolete
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
