Description
- N-Channel 30V 140A (Tc) 3.8W (Ta), 200W (Tc) Surface Mount
IRL3803STRRPBF Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 3 Pin |
| Case/Package | TO-252-3 |
| Number of Channels | 1 Channel |
| Polarity | N-CH |
| Power Dissipation | 200 W |
| Drain to Source Voltage (Vds) | 30 V |
| Continuous Drain Current (Ids) | 140A |
| Rise Time | 230 ns |
| Input Capacitance (Ciss) | 5000pF @25V(Vds) |
| Fall Time | 35 ns |
| Operating Temperature (Max) | 175 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 3.8W (Ta), 200W (Tc) |
| Show | |
| Size-Length | 6.5 mm |
| Size-Width | 6.22 mm |
| Size-Height | 2.3 mm |
| Operating Temperature | -55℃ ~ 175℃ (TJ) |
| Product Lifecycle Status | Not Recommended for New Designs |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status |
