L4963W - ST Microelectronics
Manufacturer:
ST Microelectronics
ManyChip's Part#:
MC34961771
Category:
DC to DC Converter
Package:
PDIP-18
Datasheet:
Datasheet 3D Model
Description:
Conv DC-DC 9V to 46V Step Down Single-Out 5.1V to 36V 1.5A 18Pin Power PDIP
Stock Locations:
Availability:
285 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.03

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The L4963W is a monolithic power Switching Regulator delivering 1.5A at 5.1V. The output voltage is adjustable from 5.1 to 36V, working in discontinuous variable frequency mode. Features of the device include remote inhibit, internal current limiting and thermal protection, reset and power fail outputs for microprocessor.
No frequency compensation required
Very few external components
Thermal shutdown
Discontinuous variable frequency mode
Very high efficiency
Reset and power fail output for microprocessor
Precise (±2%) on chip reference

Show

L4963W Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	18 Pin
Case/Package	PDIP-18
Number of Outputs	1 Output
Output Voltage	5.1V ~ 36V
Output Current	1.5 A
Number of Positions	18 Position
Switching Frequency	60 kHz
Input Voltage (Max)	46 V
Input Voltage (Min)	9 V
Output Voltage (Max)	36 V
Output Voltage (Min)	5.1 V
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	9 V
Input Voltage	9V ~ 46V
	Show
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
