LT1101CN8 - Linear Technology
Manufacturer:
Linear Technology
ManyChip's Part#:
MC151192234
Category:
Instrumentation Amplifier IC
Package:
PDIP
Datasheet:
Datasheet 3D Model
Description:
LT1101 - Precision, Micropower, Single Supply Instrumentation Amplifier (Fixed Gain = 10 or 100); Package: PDIP; Pins: 8; Temperature Range: 0°C to 70℃
Stock Locations:
Availability:
280 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 22.11

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Precision, Micropower, Single Supply Instrumentation Amplifier (Fixed Gain = 10 or 100)
DESCRIPTION
The LT®1101 establishes the following milestones: (1) It is the first micropower instrumentation amplifier, (2) It is the first single supply instrumentation amplifier, (3) It is the first instrumentation amplifier to feature fixed gains of 10 and/or 100 in low cost, space-saving 8-lead packages.
The LT1101 is completely self-contained: no external gain setting resistor is required. The LT1101 combines its micropower operation (75µA supply current) with a gain error of 0.008%, gain linearity of 3ppm, gain drift of 1ppm/°C. The output is guaranteed to drive a 2k load to ±10V with excellent gain accuracy.
FEATURES
■ Gain Error: 0.04% Max
■ Gain Nonlinearity: 0.0008% (8ppm) Max
■ Gain Drift: 4ppm/°C Max
■ Supply Current: 105µA Max
■ Offset Voltage: 160µV Max
■ Offset Voltage Drift: 0.4µV/°C Typ
■ Offset Current: 600pA Max
■ CMRR, G = 100: 100dB Min
■ 0.1Hz to 10Hz Noise: 0.9µVp-p Typ .3pAp-p Typ
■ Gain Bandwidth Product: 250kHz Min
■ Single or Dual Supply Operation
■ Surface Mount Package Available
APPLICATION
■ Differential Signal Amplification in Presence of ommon Mode Voltage
■ Micropower Bridge Transducer Amplifier
– Thermocouples
– Strain Gauges
– Thermistors
■ Differential Voltage-to-Current Converter
■ Transformer Coupled Amplifier
■ 4mA to 20mA Bridge Transmitter
