MAX1490BEPG+ - Maxim Integrated
Manufacturer:
Maxim Integrated
ManyChip's Part#:
MC6633344
Category:
Interface IC, Interface Controller
Package:
DIP-24
Datasheet:
Datasheet 3D Model
Description:
MAXIM INTEGRATED PRODUCTS MAX1490BEPG+ Transceiver RS422, RS485, 4.5V-5.5V supply, 1 Driver, DIP-24
Stock Locations:
Availability:
239 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 33.8

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The MAX1490BEPG+ is a complete electrically isolated RS485/RS422 data interface in 24 pin DIP package. It is a complete, electrically isolated, RS485/ RS422 data-communications interface solutions in a hybrid microcircuit. A single +5V supply on the logic side powers both sides of the interface. It features reduced slew rate driver that minimizes EMI and reduce reflections caused by improperly terminated cables allowing error free data transmission at data rates up to 250Kbps. The driver is short circuit current limited and protected against excessive power dissipation by thermal shutdown circuitry that places the driver outputs into a high impedance state. The receiver input has a fail-safe feature that has high output if the input is open circuit. Typical applications include isolated RS485/RS422 data interface, transceivers for EMI-sensitive applications, industrial-control local area networks, automatic test equipment and HVAC/building control networks.
Supply voltage range is 4.5V to 5.5V
Operating temperature range from -40°C to 85°C
Full duplex communication
Shutdown supply current is 0.2µA
FS pin to select between high and low switching frequencies for the isolated power driver
Switch frequency is 535KHz (VFS = 0V) and 725KHz (FS = VCC or open)
Typically withstand 1600Vrms (1 minute) or 2000Vrms (1 second)
