MAX232ACPE+ - Maxim Integrated
Manufacturer:
Maxim Integrated
ManyChip's Part#:
MC6066075
Category:
Interface IC, Interface Controller
Package:
DIP-16
Datasheet:
Datasheet 3D Model
Description:
MAXIM INTEGRATED PRODUCTS MAX232ACPE+ Multichannel Receiver RS232 Driver, CMOS, 200Kbps, DIP-16
Stock Locations:
Availability:
772 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 2.96

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The MAX232ACPE+ line driver/receiver is intended for all EIA/TIA-232E and V.28/V.24 communication interfaces, particularly applications where ±12V is not available. These parts are especially useful in battery powered systems, since their low power shutdown mode reduces power dissipation to less than 5µW.
2 RS-232 drivers/receivers
4 external capacitors: 0.1µF nom.
200kbps data rate
High slew rate

Show

MAX232ACPE+ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP-16
Supply Voltage (DC)	5.00 V, 12.0 V (max)
Supply Current	4.00 mA
Number of Channels	2 Channel
Number of Positions	16 Position
Data Rate	200 kbps
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	842 mW
Supply Voltage	4.5V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	Show
Size-Length	19.43 mm
Size-Width	7.87 mm
Size-Height	4.45 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
