Image is for your reference only,please check specifications for details
- MC14067BCP - ON Semiconductor
-
Manufacturer:ON Semiconductor
-
ManyChip's Part#:MC128484003
-
Category:Interface IC, Interface Controller
-
Package:DIP-24
-
Datasheet:Datasheet 3D Model
-
Description:16Channel, SGL ENDED MULTIPLEXER, PDIP24, PLASTIC, DIP-24
-
Stock Locations:
-
Availability:4 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 3.05
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Analog Multiplexers / Demultiplexers
- The MC14067 multiplexer/demultiplexer is a digitally controlled analog switch featuring low ON resistance and very low leakage current. This device can be used in either digital or analog applications.
- Features
- •Low OFF Leakage Current
- •Matched Channel Resistance
- •Low Quiescent Power Consumption
- •Low Crosstalk Between Channels
- •Wide Operating Voltage Range: 3 to 18 V
- •Low Noise
- •Pin for Pin Replacement for CD4067B
- •Pb−Free Packages are Available
MC14067BCP Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 24 Pin |
| Case/Package | DIP-24 |
| Supply Voltage (DC) | 15.0 V |
| Number of Circuits | 1 Circuit |
| Polarity | Non-Inverting |
| Power Dissipation | 500 mW |
| Bandwidth | 15 MHz |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| 3dB Bandwidth | 15 MHz |
| Power Dissipation (Max) | 500 mW |
| Show | |
| Size-Length | 32.13 mm |
| Size-Width | 14.22 mm |
| Size-Height | 4.06 mm |
| Operating Temperature | -55℃ ~ 125℃ (TA) |
| Product Lifecycle Status | Unknown |
| Packaging | Rail |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
