Image is for your reference only,please check specifications for details
- MCZ1210AH900L2TA0G - TDK
-
Manufacturer:TDK
-
ManyChip's Part#:MC366887
-
Category:Inductor Choke
-
Package:1210
-
Datasheet:Datasheet 3D Model
-
Description:90Ω @ 100MHz Common Mode Choke Surface Mount Signal Line 100mA 2 Lines 1.75Ω -40℃ ~ 85℃
-
Stock Locations:
-
Availability:295 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.04
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- 2 Line Common Mode Choke Surface Mount 90 Ohms @ 100MHz 100mA DCR 1.75Ohm
MCZ1210AH900L2TA0G Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Case/Package | 1210 |
| Voltage Rating (DC) | 5 V |
| Current Rating | 100 mA |
| Resistance | 90 Ω |
| Test Frequency | 100 MHz |
| Current Rating (Max) | 100 mA |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Voltage Rating | 5 VDC |
| Resistance (DC Max) | 1.75 Ω |
| Show | |
| Size-Length | 1.25 mm |
| Size-Width | 1 mm |
| Size-Height | 0.5 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
