NTLUD3A260PZTAG - ON Semiconductor
Manufacturer:
ON Semiconductor
ManyChip's Part#:
MC49449336
Category:
MOSFET, MOSFET Transistor
Package:
UDFN-6
Datasheet:
Datasheet 3D Model
Description:
Small Signal MOSFET -20V -1.7A 200mOhm Dual P-Channel uDFN6, UDFN6, 1.6x1.6, 0.5P Dual Flag, 3000-REEL
Stock Locations:
Availability:
1,486 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.14

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Make an effective common source amplifier using this NTLUD3A260PZTAG power MOSFET from ON Semiconductor. Its maximum power dissipation is 800 mW. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This MOSFET transistor has an operating temperature range of -55 °C to 150 °C. This P channel MOSFET transistor operates in enhancement mode.

Show

NTLUD3A260PZTAG Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	UDFN-6
Number of Positions	6 Position
Drain to Source Resistance (on) (Rds)	0.16 Ω
Power Dissipation	500 mW
Threshold Voltage	1 V
Drain to Source Voltage (Vds)	20 V
Rise Time	32.3 ns
Input Capacitance (Ciss)	300pF @10V(Vds)
Input Power (Max)	500 mW
Fall Time	74 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	1.3 W
	Show
Size-Length	1.6 mm
Size-Width	1.6 mm
Size-Height	0.5 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
