Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 4 Pin |
Case/Package | PCB Mount |
Voltage Rating (DC) | 30.0 V |
Output Voltage | 30.0 V |
Number of Channels | 1 Channel |
Forward Voltage | 1.7 V |
Wavelength | 890 nm |
Input Current | 40.0 mA |
Peak Wavelength | 890 nm |
Power Dissipation | 100 mW |
Breakdown Voltage (Collector to Emitter) | 30 V |
Forward Current | 40 mA |
Forward Current (Max) | 40 mA |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -40 ℃ |
Power Dissipation (Max) | 100 mW |
Supply Voltage | 1.7 VDC |
Show | |
Size-Length | 17.8 mm |
Size-Width | 5.1 mm |
Size-Height | 22.9 mm |
Housing Material | Plastic |
Product Lifecycle Status | Active |
Packaging | Bulk |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/06/15 |
ECCN Code | EAR99 |
