Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 8 Pin |
Case/Package | DIP |
Current Rating | 8 A |
Power Consumption | 400 mW |
Contact Current Rating | 8 A |
Coil Voltage | 24 VDC |
Coil Current | 16.7 mA |
Coil Resistance | 1.44 kΩ |
Coil Voltage (DC) | 24 V |
Input Power (Max) | 2 KVA |
Switching Current (Max) | 8 A |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -40 ℃ |
Show | |
Size-Length | 29 mm |
Size-Width | 12.7 mm |
Size-Height | 15.7 mm |
Contact Material | Silver Nickel |
Operating Temperature | -40℃ ~ 85℃ |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
HTS Code | 8536410050;8536490099 |
ECCN Code | EAR99 |
