Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 8 Pin |
Case/Package | DIP-8 |
Supply Voltage (DC) | 15.0 V |
Operating Voltage | 6V ~ 36V |
Supply Current | 1.6 mA |
Number of Circuits | 1 Circuit |
Number of Channels | 1 Channel |
Number of Positions | 8 Position |
Power Dissipation | 500 mW |
Common Mode Rejection Ratio | 140 dB |
Quiescent Current | 2 mA |
Bandwidth | 600 kHz |
Slew Rate | 300 mV/μs |
Gain Bandwidth Product | 600 kHz |
Input Impedance | 200 GΩ |
Input Offset Voltage | 10 µV |
Input Bias Current | 1.2 nA |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -40 ℃ |
Gain Bandwidth | 130 dB |
Power Dissipation (Max) | 500 mW |
Minimum CMRR Range | 130 dB |
Supply Voltage (Max) | 36 V |
Show | |
Size-Length | 9.27 mm |
Size-Width | 7.24 mm |
Size-Height | 3.43 mm |
Operating Temperature | -40℃ ~ 85℃ |
Product Lifecycle Status | Active |
Packaging | Each |
RoHS | RoHS Compliant |
Lead-Free Status | Contains Lead |
REACH SVHC Compliance | No SVHC |
Mil-Spec | No |
REACH SVHC Compliance Edition | 2015/12/17 |
