- OPA544T - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC504100
-
Category:Operational Amplifier, OP Amp IC
-
Package:TO-220-5
-
Datasheet:Datasheet 3D Model
-
Description:Operational Amplifier, Single, 1 Amplifier, 1.4MHz, 8V/µs, ± 10V to ± 35V, TO-220, 5Pins
-
Stock Locations:
-
Availability:4,135 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 14.8
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The OPA544T is a high-voltage/high-current Operational Amplifier, suitable for driving a wide variety of high power loads. High performance FET operation amplifier circuitry and high power output stage are combined on a single monolithic chip. The OPA544T is protected by internal current limit and thermal shutdown circuits. Its copper tab allows easy mounting to a heat sink for excellent thermal performance. It is specified for operation over the extended industrial temperature range, -40 to +85°C.
- 2A (minimum) High output current
- Internal current limit
- Thermal shutdown protection
- B = 100pA Maximum FET input
- IC can be damaged by ESD. We recommend that all ICs be handled with appropriate precautions. Failure to observe proper handling and installation procedures can cause damage.
OPA544T Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 5 Pin |
| Case/Package | TO-220-5 |
| Supply Voltage (DC) | 35.0 V |
| Operating Voltage | 10V ~ 35V |
| Supply Current | 12 mA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Number of Positions | 5 Position |
| Common Mode Rejection Ratio | 90 dB |
| Input Offset Drift | 10.0 µV/K |
| Bandwidth | 1.4 MHz |
| Slew Rate | 8.00 V/μs |
| Gain Bandwidth Product | 1.4 MHz |
| Input Offset Voltage | 1 mV |
| Input Bias Current | 15 pA |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Gain Bandwidth | 1.4 MHz |
| Minimum CMRR Range | 90 dB |
| Show | |
| Size-Length | 10.16 mm |
| Size-Width | 4.58 mm |
| Size-Height | 8.51 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Each |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| ECCN Code | EAR99 |
