Description

The REF5025-HT is a low-noise, very low-drift, very high precision voltage references. This reference is capable of both sinking and sourcing, and is very robust with regard to line and load changes.
Excellent temperature drift and high accuracy are achieved using proprietary design techniques. These features, combined with very low noise, make the REF5025-HT suitable for use in high-precision data acquisition systems.
The device is offered in HKJ and HKQ packages, as well as Known-Good-Die (KGD) form, and is specified from –55°C to +210°C.

Show

REF5025SHKJ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	CFP-8
Capacitance Tolerance	±0.9 %
Input Voltage (DC)	3.25V ~ 18.0V
Output Voltage	2.5 V
Output Current	7 mA
Supply Current	1.5 mA
Number of Channels	1 Channel
Quiescent Current	800 µA
Input Voltage (Max)	18 V
Output Voltage (Max)	2.5 V
Output Voltage (Min)	2.5 V
Output Current (Max)	10 mA
Operating Temperature (Max)	210 ℃
Operating Temperature (Min)	-55 ℃
Input Voltage	3.25V ~ 18V
	Show
Operating Temperature	-55℃ ~ 210℃ (TA)
Temperature Coefficient	±40 ppm/℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance Edition	2015/06/15
